BASIC CABLE INFORMATION:

  • Part Number:
  • DLY7379
  • Type and Specification:
  • 21602K26 3×18AWG
  • Packing Information:
  • 300 meter per reel
  • Cable Color:
  • Black

APPLICATION:

Elevator suspension cable for indoor and panoramic elevators.

INSTALLATION:

To comply with the correct installation procedures please refer to the Changshun Product Catalog which is available separately.
Download PDF

THE COMPOSITION STRUCTURE AND SPECIFIC INFORMATION OF CABLE ARE AS FOLLOWS:

Component Core Wire 3/18AWG
Conductor  Material TR Soft Copper Wire
Insulation   Material PVC Class 4

THE CONDUCTOR NUMBERING ARE AS FOLLOWS:

Size Conductor Number And Color
18AWG Yellow and Green 003、Red and White 122、Red 123

THE MECHANICAL PROPERTIES:

Operating Temperature(℃): 60
Cable Net Weight Approx. (lbs/kft [kg/km]): 24.86[37.00]
Overall Dimensios Approx. (W/H, in [mm]): 0.185[4.7]
Copper Content.(lbs/kft [kg/km]): 15.19[22.60]
Flame property: FT1

THE ELECTRICAL PROPERICAL:

Maximum Voltage: 300V
The conductor resistance of the 14 AWG(Ω/km): ≤8.88
The conductor resistance of the 18 AWG(Ω/km): ≤22.4
The conductor resistance of the 20 AWG(Ω/km): ≤35.7

CERTIFICATION & STANDARDS:

Certification:
CSA File Number: 253817
CSA Standard: CSA C22.2 No.49
UL Standard: UL 758、UL1581
